Product Details
Color
Grey
Voltage
440V
Power
3-5kw
Warrenty
1 Year
Features :
- Inner tank of SS 316 and outer tank of SS304.
- Insitu PUF insulation for brine tank.
- Brine spray system made of SS.
- Less time required for starting and easy to clean due to less quantity of brine in the system.
- Suitable for continuous production without any interruption.
- Pre wired electric control panel with thermostat and all safeties.
Specifications
| Model | 4 MOULD | 10 MOULD | 20 MOULD |
| Capacity, Pcs./hr. | 375 | 950 | 1900 |
| Brine Pump, kW | 1.5 | 2.25 | 3.75 |
| Compressor, kW | 2.8 | 6.58 | 15 |
| Compressor, Type | Hermetic | Hermetic | Semi Hermetic |
| Refrigerant | R – 404 A | R – 404 A | R – 404 A |
| Condenser | Water Cooled | Water Cooled | Water Cooled |
| Water Flow Rate at 30°C, l/hr | 2000 | 5000 | 10000 |
| Length, mm | 1625 | 2248 | 2298 |
| Width, mm | 723 | 723 | 1218 |
| Height, mm | 1305 | 1295 | 1455 |
